Novastar MSD300 Sending Card
1. MSD300 Sending Card Description:
1). DVI video input
2). Audio transmission
3). Dual-Ethernet output, with dual-Ethernet cable hot backup and multiple controller hot backup.
4). USB port control, for cascading and control of multiple units.
5). 1.3 million pixel loading capacity, with resolutions of 1280×1024@60Hz, 1024×1200@60Hz, 1600×848@60Hz, 1970×712@69Hz, 2048×668@60Hz.
6). CE / RoHS / EAC / FCC / IC
2. MSD300 Sending Card Features:
1). 1 × DVI video input and 1 × audio input
2). 2 × Gigabit Ethernet output
3). 1 × light sensor connector
4). Supports the new generation of pixel level calibration technology from NovaStar to provide a fast and efficient calibration process.
5). Supports a variety of video formats.
3. MSD300 Sending Card Specifications:
Indicator |
|
| Red |
Device operating indicator. Working status:
|
| Green |
Device status indicator. Working status:
|
Input |
|
| DVI×1 |
|
| AUDIO | Audio input connector |
| Output | |
| RJ45×2 |
|
Control |
|
| USB (Type-B) | Connects to the PC. |
| UART IN/OUT | Input/Output connector for cascading devices |
| Function Connector | |
| LIGHT SENSOR | Connects to a light sensor to monitor ambient brightness, allowing for automatic brightness adjustment of LED display. |
| Power Supply | |
| DC 3.3V~5.5V | DC power connector |
| FILE NAME | RELEASE NOTES | SPECIFICATIONS | FIRMWARE |
|---|---|---|---|
| MSD300 Sending Card | Release Notes | Specifications | Firmware |
Novastar Mctrl300 LED Display Controller
MCTRL300 is novastar’s independent control card from the M3 Series, and supports audio and video input. The M3 undertakes encoding and data processing, sending the audio and video to the display. A single card supports maximum loading capacity of 2048×668@60Hz. It communicates with PC via USB port for convenience.
1. Mctrl300 LED Display Controller Description:
1). DVI video input
2). Audio transmission
3). Dual-Ethernet output, with dual-Ethernet cable hot backup and multiple controller hot backup
4). USB port control, for cascading and control of multiple units
5). 1.3 million pixel loading capacity, with resolutions of 1280×1024@60Hz, 1024×1200@60Hz, 1600×848@60Hz, 1920×712@69Hz, 2048×668@60Hz and Maximum height: 3840; Maximum height:3840
6). 1 light sensor interface, adjust the screen brightness automatically
7). Independent power supply
8). Certifications: CE, RoHS, EAC, FCC, IC
2. Mctrl300 LED Display Controller Features:
1). 1 × DVI input
2). 1 × audio input
3). 1 × type-B USB control port
4). ART control ports to cascade devices for uniform control.
5). Dual Ethernet outputs.
6). Supports the new generation of NovaStar calibration technology, which is fast and efficient.
7). 1 × light sensor connector.
8). Supports resolutions up to 2048×668@60Hz and downward compatibility.
9). Supports a variety of video formats.
3. Mctrl300 LED Display Controller Specifications:
Connector | Connector Name | Description |
| Input | DVI IN |
|
| AUDIO | Audio input connector | |
| Output | RJ45 × 2 |
|
| Function | LIGHT SENSOR | Connect to light sensor to monitor ambient brightness to realize automatic screen brightness adjustment. |
| Connector | Connector Name | Description |
| Control | UART IN/OUT | Input and output ports for cascading devices |
| USB | Type-B USB control port for connecting to PC | |
| Power | AC 100V-240V~50/60Hz | |
| Indicators | ||
| RUN | Device operating indicator. Working status:
| |
| STATUS | Device power indicator. Working status:
| |
| FILE NAME | RELEASE NOTES | SPECIFICATIONS | FIRMWARE |
|---|---|---|---|
| Mctrl300 Sending Controller | Release Notes | Specifications | Firmware |
